P2.5 P3 P4 P5 P6 Indoor Outdoor Full Color Rental RGB Advertising LED Display Panel Large Video Wall Screens Thin Waterproof Display Panel Billboard Module

Customization: Available
Tube Chip Color: Full Color
Display Function: Video Display, Image & Text Display, Text Display, Market Display

Product Description

i

Basic Specifications

Model NO.:LW-FI 3
Pixel Pitch:3mm
Pixel Configuration:1R,1G,1B
Pixel Density:111111 / M²
Scanning Mode:1/16 Scan
Operating Platform:Win7 XP Vista
Display Type:LED Video Display
Application:Stage, Advertising, Shopping Guide
Certification:CE, RoHS, CCC, FCC, ETL
LED Type:SMD2020
Viewing Angle:H:140 V:140
Cabinet Material:Aluminum
Cabinet Size:384X384 mm
Cabinet Weight:9kg
MTBF:10000h
Production Capacity:5000sq. M/Month

Product Description & Features

P2.5 P3 P4 P5 P6 Indoor Outdoor RGB LED Display Panel Video Wall Screen

  • High definition videos and pictures for superior visual impact
  • Customizable cabinet dimensions to fit specific requirements
  • Supports both front and rear service with magnetic modules
  • Silent fan technology for noise-free operation
  • High refresh rate up to 3840 HZ
  • Ultra-wide viewing angle (H:140°, V:140°)
  • Stacking installation design for easy setup
T

Technical Parameters

Items P2.5mm P3mm P4mm P5mm P6mm P10mm
Pixel ConfigurationSMD 3-in-1SMD 3-in-1SMD 3-in-1SMD 3-in-1SMD 3-in-1SMD 3-in-1
Pixel Density160,000111,11162,50040,00027,77710,000
Module Size(mm)160x160192x192256x128320x160192x192320x160
Cabinet Size(mm)960x960960x9601024x1024960x960960x960960x960
Brightness1300cd/㎡1300cd/㎡1300cd/㎡1300cd/㎡1300cd/㎡1000cd/㎡
Refresh Rate300-3000HZ adjustable
LED Life100,000 hours
Gray ScaleRed, Green, and Blue each 16K
P

Project Case & Product Details

?

Frequently Asked Questions

What kind of displays do you provide?
We provide indoor, outdoor, rental, taxi top, mobile LED displays, stage displays, and irregular LED displays for various applications.
What is the production lead time?
Production typically takes about 10-25 working days. Once the order is confirmed and the deposit is received, we begin manufacturing and provide regular updates.
How are the products packaged for shipping?
For fixed installations, we use wooden cases (usually 2-4 cabinets per case). For the rental market, we recommend flight cases (generally 8 cabinets per case) for better protection and mobility.
Can the LED screen play HD video?
Yes, our screens can achieve HD video functionality using advanced control systems like Linsn or Novastar.
What is the difference between DIP and SMD?
SMD (3-in-1) integrates three chips into one LED lamp, improving uniformity, grainy texture, and viewing angles. Traditional DIP uses three separate lamps per pixel. SMD is now widely used for both indoor and outdoor due to technological advancements.
What are the delivery terms?
We accept various delivery terms including EXW, FOB, CFR, CIF, DDU, and DDP to suit your convenience and cost-effectiveness.
