Programmable Bus LED Moving Message Display with High Resolution

Still deciding? Get samples of $ !

Request Sample

Send Inquiry

Product Description

Technical Specifications

Model

P7.62

Pixel Pitch

7.62mm

Configuration

1R, 1G, 1B

Function

Image & Text Display

Power Avg.

220W / m²

Pixel Density

17222 DOT/M2

Scan Mode

1/4 Scan

Type

LED Dot Matrix

Application

Advertising / Bus

Certification

CE, RoHS

Capacity

45000 pieces/Month

HS Code

8531200000

Product Overview

Specializing in LED electronic displays for real-time bus information, these solutions have been deployed across thousands of transit points, including buses, trams, and bus stops. These electronic displays deliver clear, real-time information to passengers, significantly enhancing the travel experience. Our displays are versatile, showing bus service numbers, destinations, schedules, current time, and advertisements, with custom-tailored dimensions to meet specific requirements.

⚙️ Easy Operation

Update messages via USB flash drive. Drivers can select stored routes easily via integrated buttons.

🌍 Multi-Language

Self-defined English and Spanish fonts, specifically optimized for international regions.

💡 High Brightness

Utilizes Taiwan Epistar 12mil/14mil LED chips for high brightness, low heat, and extended lifespan.

🔋 Energy Efficient

Automatic brightness control saves energy and prolongs display life based on ambient light.

Detailed Specifications

NO.	Item	Specification
1	Type of LED	SMD3528
2	LED Color	RGB
3	Pitch	12mm horizontal, 12mm vertical
4	Line Resolution	32 * 160
5	Character Height	284mm
6	Visibility	60-100 meters
7	Viewing Angle	120°H / 60°V
8	Languages	English, Spanish, Portuguese, Regional fonts
9	Brightness	Inbuilt light sensor, automatic or 4-class manual set
10	Data Interface	Wireless, RS232 / 485
11	Controller	999 routes / 1000 stations per route
12	Voltage Range	DC 12V ~ 36V
13	Operating Temp	-40ºC to +80ºC
14	Life Span	>100,000 hours
15	Cabinet Material	Aluminium

Product Showcase

Frequently Asked Questions

1. How do I update the information on the LED bus display?

The message can be easily updated via a USB flash drive. Additionally, drivers can select pre-stored routes using dedicated hardware buttons.

2. Does the display support languages other than English?

Yes, it supports self-defined English, Spanish, and Portuguese fonts, along with other regional languages as required.

3. Can the brightness be adjusted for day and night use?

The display features an inbuilt light sensor that automatically adjusts brightness. It also supports manual settings at 25%, 50%, 75%, and 100% levels.

4. What is the power requirement for these displays?

The displays operate within a wide DC voltage range of 12V to 36V, making them suitable for various types of transit vehicles.

5. Is the LED display durable for extreme weather conditions?

Yes, it is designed to operate in temperatures ranging from -40ºC to +80ºC. If IP65 protection is required, an optional organic glass cover can be added.

6. How many routes can be stored in the controller?

The inbuilt controller can store up to 999 routes with up to 1000 stations per route.
